Additional information
| Sensor | 1/2", 8.0 megapixel, CMOS, progressive scan |
|---|---|
| Lens | 2.8 ~ 12mm, AF automatic focusing and motorized zoom lens |
| DORI Distance Lens (mm) | 2.8 ~ 12mm |
| DORI Distance Detect | 63 ~ 270mm |
| DORI Distance Observe (m) | 25.2 ~ 108mm |
| DORI Distance Recognize (m) | 12.6 ~ 54m |
| Angle of View (H) | 114.8° ~ 47.3° |
| Angle of View (V) | 75.3° ~ 20.4° |
| Angle of View (O) | 141.2° ~ 55.8° |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Minimum Illumination | Colour: 0.001Lux (F1.5, AGC ON) 0Lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| IR Range | Up to 50m (164ft) IR range |
| Wavelength | 850nm |
| Video Compression | H.264, H.265, MJPEG, Ultra 265 |
| Frame Rate | Main Stream: 8MP (3840*2160), Max 20fps; 5MP (2592*1944), Max 30fps; 5MP (2944*1656), Max 30fps; 4MP (2560*1440), Max 30fps; 2MP (1920*1080), Max 60fps;, Sub Stream: 2MP (1920*1080), Max 30fps;, Third Stream: D1 (720*576), Max 30fps |
| Video Bit Rate | 128 Kbps~16 Mbps |
| OSD | Up to 8 OSDs |
| White Balance | Auto, Auto2, Fine Tune, Locked, Outdoor, Sodium Lamp |
| Digital noise reduction | 2D/3D DNR |
| Edge Storage | Micro SD, up to 256GB |
| Network Storage | ANR, NAS(NFS) |
